Off-the-road valves
TRJ650-02/03
 |
 |
||||||
| TRJ650-02 | TRJ650-03 | ||||||
| Premier No. | L1(mm) | L2(mm) | α | Rim Hole(mm) | Accessories | ||
| Core | Cap | Spud | |||||
| TRJ-650-02/03 | 27 | 79 | 80° | 20.5 | 7002 | VC6 | TRSP2 |
| TRJ-651-02/03 | 32 | 119 | 90° | 20.5 | 7002 | VC6 | TRSP2 |
| TRJ-652-02/03 | 27 | 140 | 86° | 20.5 | 7002 | VC6 | TRSP2 |
| TRJ-653-02/03 | 27 | 64 | 80° | 20.5 | 7002 | VC6 | TRSP2 |
| TRJ-654-02/03 | 27 | 79 | 60° | 20.5 | 7002 | VC6 | TRSP2 |
| TRJ-655-02/03 | 27 | 79 | 74° | 20.5 | 7002 | VC6 | TRSP2 |
| TRJ-656-02/03 | 67 | 94 | 90° | 20.5 | 7002 | VC6 | TRSP2 |
| TRJ-657-02/03 | 27 | 102 | 80° | 20.5 | 7002 | VC6 | TRSP2 |
| TRJ-658-02/03 | 27 | 140 | 80° | 20.5 | 7002 | VC6 | TRSP2 |
| TRJ-659-02/03 | 48 | 89 | 90° | 20.5 | 7002 | VC6 | TRSP2 |
| TRJ-660-02/03 | 48 | 222 | 90° | 20.5 | 7002 | VC6 | TRSP2 |
| TRJ-669-02/03 | 27 | 64 | 90° | 20.5 | 7002 | VC6 | TRSP2 |
TRJ-670
 |
 |
| TRJ-670 Large bore core housing |
TRJ-670-2 TRJ-670 assembled with 7002 core and VC7 cap |
 |
|
| TRJ-670-3 TRJ670 assembled with 7002 core, VC7 cap and TRSP2 spud. |
|
TRJ4000
This valve can be used with TRSP2 tubeless spud or TRSP4000 tube spud
For length over 6"/152mm, 2 hex nuts BN3 are fitted.
 |
|
| TRJ4000 | |
| Premier No. | L (inch) | L (mm) | α | Accessories | |||
| Core | Cap | Nut | O-ring | ||||
| TRJ4000-2.5 | 2 1/2" | 64 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-3 | 3" | 76 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-4 | 4" | 102 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-4.5 | 4 1/2" | 114 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-6 | 6" | 152 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-7.5 | 7 1/2" | 191 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-8 | 8" | 203 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-8.5 | 8 1/2" | 216 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-9 | 9" | 229 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-10 | 10" | 254 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-10.5 | 10 1/2" | 267 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-12 | 12" | 305 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-16 | 16" | 406 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-20 | 20" | 508 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-24 | 24" | 610 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-25.5 | 25 1/2" | 648 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-28 | 28" | 711 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-29.5 | 29 1/2" | 749 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
| TRJ4000-30 | 30" | 762 | 90° | 7002 | VC6 | BN3 | V9-11-3 |
TRSP1000
TRSP1000 Rubber spud for TRSP4000 and screw on repair valve
TRAD4
TRAD4 Large bore tube spud adapter
